DNSBL Resolving Some Domains To 10.10.10.1 But Does Not Log Them

dma_pf

DNSBL is blocking some domains but the events do not show up in the Alerts tab in pfblockerng-devel (v3.2.10). I ran a pcap on the client via pfsense (2.8.1-RELEASE) and loaded it into Wireshark. Here is a a snippet of the pcap:

acac-8434ae288494-pcap-resized.png) image url)
The first line is the actual dns request from the client trying to resolve dns.msftncsi.com. The actual query in the pcap was:

        dns.msftncsi.com: type A, class IN
            Name: dns.msftncsi.com
            [Name Length: 16]
            [Label Count: 3]
            Type: A (Host Address) (1)
            Class: IN (0x0001

The second line was the answer to the query which was:

Answers
            dns.msftncsi.com: type A, class IN, addr 10.10.10.1
                Name: dns.msftncsi.com
                Type: A (Host Address) (1)
                Class: IN (0x0001)
                Time to live: 3600 (1 hour)
                Data length: 4
                Address: mobile.events.data.microsoft.com (10.10.10.1)

And the following lines are all the attempts following the DNS query where the client tried to connect to mobile.events.data.microsoft.com at 10.10.10.1:443. None of these events were logged in the Alerts tab in pfblockerng.

I verfied that both dns.msftncsi.com and mobile.events.data.microsoft.com are in DNSBL:

grep "dns.msftncsi.com" /var/db/pfblockerng/dnsbl/*.txt
/var/db/pfblockerng/dnsbl/Crazy_Max_Extra.txt:,dns.msftncsi.com,,1,Crazy_Max_Extra,DNSBL_MSFT_Crazy_Max
/var/db/pfblockerng/dnsbl/Maltrail_BD.txt:,dns-msftncsi.com,,1,Maltrail_BD,DNSBL_Malicious

grep "mobile.events.data.microsoft.com" /var/db/pfblockerng/dnsbl/*.txt
/var/db/pfblockerng/dnsbl/Crazy_Max_Extra.txt:,mobile.events.data.microsoft.com,,1,Crazy_Max_Extra,DNSBL_MSFT_Crazy_Max
/var/db/pfblockerng/dnsbl/EasyPrivacy.txt:,eu-mobile.events.data.microsoft.com,,1,EasyPrivacy,DNSBL_EasyList
/var/db/pfblockerng/dnsbl/Lightswitch05.txt:,eu.mobile.events.data.microsoft.com,,1,Lightswitch05,DNSBL_Firebog_Trackers
/var/db/pfblockerng/dnsbl/Lightswitch05.txt:,uk-mobile.events.data.microsoft.com,,1,Lightswitch05,DNSBL_Firebog_Trackers
/var/db/pfblockerng/dnsbl/Lightswitch05.txt:,uk.mobile.events.data.microsoft.com,,1,Lightswitch05,DNSBL_Firebog_Trackers
/var/db/pfblockerng/dnsbl/Lightswitch05.txt:,us-mobile.events.data.microsoft.com,,1,Lightswitch05,DNSBL_Firebog_Trackers
/var/db/pfblockerng/dnsbl/Lightswitch05.txt:,us.mobile.events.data.microsoft.com,,1,Lightswitch05,DNSBL_Firebog_Trackers

Can someone explain why the events were not logged? And the other strange thing that I don't understand is why the answer to the DNS query would have provided the address of mobile.events.data.microsoft.com (10.10.10.1). How is it that the DNSBL Webserver would resolve dns.msftncsi.com to mobile.events.data.microsoft.com and given that response?

tinfoilmatt

@dma_pf Debt collector, or debt relief service?
