    OpenVPN and static IP for ALL clients

    OpenVPN
    7
    27
    668
    Loading More Posts
    • Oldest to Newest
    • Newest to Oldest
    • Most Votes
    Reply
    • Reply as topic
    Log in to reply
    This topic has been deleted. Only users with topic management privileges can see it.
    • V
      vjfromgt last edited by

      I have seen documentation on how to assign a static ip per vpn configuration but I need all my clients to have static ips, whatever IP the get the first time they connect should be the ip they always get.

      Is there a setting for this?
      Is there a setting for the config to always assign an available ip when creating a new client account?

      Thanks

      1 Reply Last reply Reply Quote 0
      • Rico
        Rico LAYER 8 Rebel Alliance last edited by

        VPN > OpenVPN > Client Specific Overrides
        Make sure the Common Name matches the User Cert exactly. Define the User static IP in IPv4 Tunnel Network.
        Say your tunnel network is 10.30.8.0/24 and you want this User to have 10.30.8.11 fill in 10.30.8.11/24

        -Rico

        1 Reply Last reply Reply Quote 1
        • V
          vjfromgt last edited by

          Thanks for your reply
          This must be done per account
          I am looking for a way for this to be done with every single account in some automated method

          1 Reply Last reply Reply Quote 0
          • Rico
            Rico LAYER 8 Rebel Alliance last edited by

            Not that I'm aware of.
            I always do this right after creation of the new User and Client Export. So this cost me like 5 more seconds, no big deal.
            Why do you need static IPs anyway if you don't care about the actual IP the User gets? I need them because of a different Firewall Ruleset per User, so .11 and .12 could be a huge difference here in what the User can access or not. ☺

            -Rico

            1 Reply Last reply Reply Quote 0
            • V
              vjfromgt last edited by

              I use the endpoint to send data to them
              I need to configure where to send data to.

              How does numbering work ? Every VPN need 3 ips?

              1 Reply Last reply Reply Quote 0
              • Pippin
                Pippin last edited by

                Tunnel subnet size - 4 = nr. of clients
                /24 - 4 = 252 clients
                /25 - 4 = 124 clients
                etc.

                1 Reply Last reply Reply Quote 0
                • T
                  ThePieMonster last edited by

                  @Rico
                  I just tried this myself and was not able to get the client to have a static IP.

                  The server tunnel network is 10.1.200.0/24.
                  The client has its own cert.
                  That certs common name is entered in the Common Name field in the client override section.
                  Also the IPv4 Tunnel Network is 10.1.200.100/24 for the client override.

                  Client just ends up getting the next available address from DHCP still...

                  1 Reply Last reply Reply Quote 0
                  • noplan
                    noplan last edited by noplan

                    hi there
                    client specific override the way it works.

                    1. IPv4 Tunnel Network ip that client shall receive eg 1.2.3.4/24
                    2. in Advanced fill in: ifconfig-push 1.2.3.4 255.255.255.0;
                    3. Server List select a / the server

                    3)Common Name & Description must be exactly the same as used when u created the user
                    i personally do a copy n paste in user management for username full name and the cert for the user

                    4)restart openVPN server EDIT: (not nescenecessary)

                    1. export your credentials .... done

                    what i learned that sometimes at the first connect of the client with client spec override
                    the assigned IP will not be assigned. DIsconnect the client, restart the openVPN service and it works, disconnecting and connecting after 5 minutes also works.

                    if there are any improvements, or things to do better feel free to comment

                    brNP

                    T 1 Reply Last reply Reply Quote 0
                    • Rico
                      Rico LAYER 8 Rebel Alliance last edited by

                      Restarting the OpenVPN server because of adding some CSO? That would be a massive pain and I never had to do that.
                      I also nerver had to fill Advanced / ifconfig-push...

                      -Rico

                      1 Reply Last reply Reply Quote 0
                      • noplan
                        noplan last edited by

                        ok restartin is a true pain in the .. .
                        and it is workin without restarting. (true)

                        without Advanced / ifconfig-push... not workin here
                        to true for all devices on some it does on some it does not
                        with Advanced / ifconfig-push... workin like a charm and no problems

                        out of the blue any side effect / disadvantages cuz of usin ifconfig-push ?

                        brNP

                        1 Reply Last reply Reply Quote 0
                        • V
                          vjfromgt last edited by

                          On my linux box, I have a script which creates client accounts and sets ips
                          can something like this be done?

                          1 Reply Last reply Reply Quote 0
                          • T
                            ThePieMonster @noplan last edited by

                            @noplan said in OpenVPN and static IP for ALL clients:

                            ifconfig-push 1.2.3.4 255.255.255.0;

                            What is wrong with the below setup?
                            The domain username is not TEST (it is DOMAIN\USERNAME, actually I don't even enter the DOMAIN\ part when authenticating with the OpenVPN prompt), but that shouldn't matter correct? It's just based off the CN name?

                            alt text
                            alt text

                            1 Reply Last reply Reply Quote 0
                            • noplan
                              noplan last edited by noplan

                              i use this here (and remember i use exact copy n paste) in:




                              and still in User Management:
                              u have to klick Crate a user certificate



                              and in client spec overrides :


                              and it works ...
                              read my other comments in this post why i use Advanced / ifconfig-push...

                              (edit 10/04/20 more screenshots as requested)

                              brNp

                              1 Reply Last reply Reply Quote 0
                              • T
                                ThePieMonster last edited by

                                @noplan said in OpenVPN and static IP for ALL clients:

                                i use this here (and remember i use exact copy n paste) in:




                                and in:


                                and in client spec overrides :


                                and it works ...
                                read my other comments in this post why i use Advanced / ifconfig-push...

                                brNp

                                Can you take larger screenshots to see more of the page? I'm not sure where this username field would be...

                                noplan 1 Reply Last reply Reply Quote 0
                                • noplan
                                  noplan @ThePieMonster last edited by

                                  @ThePieMonster

                                  done added more screenshots

                                  T 1 Reply Last reply Reply Quote 0
                                  • T
                                    ThePieMonster @noplan last edited by ThePieMonster

                                    @noplan said in OpenVPN and static IP for ALL clients:

                                    @ThePieMonster

                                    done added more screenshots

                                    So my users are domain users. How would using the User Manager certificate work?

                                    This link shows that using User Certificates is not part of the process.
                                    https://fastinetserver.wordpress.com/2013/03/09/pfsense-openvpn-static-ip-for-clients/

                                    Pictures for location reference

                                    User Manager User Certificate

                                    Certificate Manager Certificate

                                    1 Reply Last reply Reply Quote 0
                                    • noplan
                                      noplan last edited by

                                      hey @ThePieMonster

                                      dont get me wrong ...
                                      add a user / click to add a user certificate
                                      and follow the instructions here in that post. and test it if it works for you then go to the next step.
                                      (all of the information you need is provided here)

                                      as far as i m concerned the link --> klick you provided is a) from 2013 and b) mentions as u can see in the screenshot
                                      that User Certificates is part of the process.


                                      possibly the next step my be
                                      check how to import the DOMAIN User Cert to pfS ore use the domainUserDB as Backend in pfS
                                      and test the whole loop again, let me mention that it would be pretty sweet when you keep us all informed how it works / or even not. But this is not part of this topic i think, cuz static IP for VPN-clients is pretty much solved here.

                                      br nP

                                      1 Reply Last reply Reply Quote 0
                                      • viktor_g
                                        viktor_g Netgate last edited by

                                        If you need per-client firewall rules, a more efficient way is to use Cisco-AVPair RADIUS ACLs:
                                        https://docs.netgate.com/pfsense/en/latest/book/openvpn/controlling-client-parameters-via-radius.html

                                        noplan 1 Reply Last reply Reply Quote 0
                                        • noplan
                                          noplan @viktor_g last edited by

                                          @viktor_g

                                          oh yeah i like that, but lack of useCase :(

                                          i think @ThePieMonster needs a static IP for his vpn-clients
                                          but a static Ip only helps when rules are set ;) so whats NEXT !

                                          1 Reply Last reply Reply Quote 0
                                          • T
                                            ThePieMonster last edited by

                                            @noplan @viktor_g

                                            As I mentioned the user cert is from the the Certificate Manager / Certificates section of pfSense, not from the User Manager section. There are two locations where a user certificate can be created.

                                            I also found out today, that the common name, is not the CN name of the cert, that can be whatever you like, but the username of the domain user. Switching this info around in the client override solved the issue for me.

                                            TLDR: CN = Domain Username, not Certificate name.

                                            viktor_g 1 Reply Last reply Reply Quote 0
                                            • noplan
                                              noplan last edited by

                                              @ThePieMonster said in OpenVPN and static IP for ALL clients:

                                              Switching this info around in the client override solved the issue for me.

                                              so please mark this posting als SOLVED !

                                              T 1 Reply Last reply Reply Quote 0
                                              • T
                                                ThePieMonster @noplan last edited by

                                                @noplan I would but I'm not OP. :)

                                                1 Reply Last reply Reply Quote 0
                                                • stephenw10
                                                  stephenw10 Netgate Administrator last edited by

                                                  There seems to be some mis-information in this thread.

                                                  You do not need to add the custom push line in a Client Specific Override. Adding the tunnel network as an IP address already does exactly that.

                                                  You often do need to restart the OpenVPN server to read in the CSOs: https://redmine.pfsense.org/issues/10337
                                                  That should probably be marked a feature though, nothing has changed there.

                                                  Steve

                                                  noplan 1 Reply Last reply Reply Quote 2
                                                  • noplan
                                                    noplan @stephenw10 last edited by

                                                    @stephenw10 said in OpenVPN and static IP for ALL clients:

                                                    You do not need to add the custom push line in a Client Specific Override

                                                    as i mentioned earlier
                                                    the reason why i added it and still doin it

                                                    there are clinets out there in the wild where the CSO is not working without
                                                    the custom push added.

                                                    thanks for pointin me to issue 10337

                                                    brNP
                                                    #staysafe

                                                    1 Reply Last reply Reply Quote 0
                                                    • viktor_g
                                                      viktor_g Netgate @ThePieMonster last edited by

                                                      @ThePieMonster said in OpenVPN and static IP for ALL clients:

                                                      @noplan @viktor_g

                                                      I also found out today, that the common name, is not the CN name of the cert, that can be whatever you like, but the username of the domain user. Switching this info around in the client override solved the issue for me.

                                                      TLDR: CN = Domain Username, not Certificate name.

                                                      You can change this behavior on 2.5 branch,
                                                      or by applying patch https://redmine.pfsense.org/issues/8289 on 2.4.4/2.4.5

                                                      1 Reply Last reply Reply Quote 0
                                                      • stephenw10
                                                        stephenw10 Netgate Administrator last edited by stephenw10

                                                        I would suggest those clients must have typo or similar because adding the custom line does exactly the same thing.
                                                        For example I created a CSO for a user with a cert CN of test and added only this:


                                                        If I check what that actually creates:

                                                        [2.4.5-RELEASE][admin@google.stevew.lan]/root: cat /var/etc/openvpn-csc/server2/test
                                                        ifconfig-push 10.10.10.5 255.255.255.240


                                                        If I now add the custom line in addition:


                                                        I now get:

                                                        [2.4.5-RELEASE][admin@google.stevew.lan]/root: cat /var/etc/openvpn-csc/server2/test
                                                        ifconfig-push 10.10.10.5 255.255.255.240
                                                        ifconfig-push 10.10.10.5 255.255.255.240


                                                        Clearly both those lines are not required! 😉

                                                        Steve

                                                        1 Reply Last reply Reply Quote 0
                                                        • noplan
                                                          noplan last edited by

                                                          @stephenw10

                                                          tested it with some older android clients right now
                                                          without the ifconfig-push not working on device
                                                          added the lines working
                                                          maybe / pretty shure it is the client not the config on the Server

                                                          1 Reply Last reply Reply Quote 0
