    Accessing Multiple VDSL Modem Web Interfaces

    Scheduled Pinned Locked Moved NAT
    4 Posts 2 Posters 456 Views
    Loading More Posts
    • Oldest to Newest
    • Newest to Oldest
    • Most Votes
    Reply
    • Reply as topic
    Log in to reply
    This topic has been deleted. Only users with topic management privileges can see it.
    • N
      neocleous
      last edited by

      Hi everyone,

      I am unable to access my modems web interface despite it being configured as the Netgate documentation specifies. This did work for a time when I had one WAN however adding the second seemed to cause an issue and I was unable to access the first modem so I reconfigured the subnet to /30 for each of the access interfaces (and on the modems). I have set up individual NAT rules for each Modem access network and put them to the top of the list.

      The modems are Draytek Vigor 130's in bridge mode set with static IP address in their respective networks.

      WAN - PPPoE
      WAN2 - PPPoE
      LAN- 192.168.0.0/24
      Modem access WAN1 192.168.2.0/30
      Modem access WAN2 192.168.2.4/30

      I hope I have been clear in explain my configuration, if there are any logs or screen shots that might be helpful please let me know.

      Thanks

      1 Reply Last reply Reply Quote 0
      • N
        neocleous
        last edited by

        I'm thinking I may have posted this in the wrong sub forum, does anyone have any suggestions on where it should go?

        1 Reply Last reply Reply Quote 0
        • pttP
          ptt Rebel Alliance
          last edited by

          Have you readed ? https://docs.netgate.com/pfsense/en/latest/interfaces/accessing-modem-from-inside-firewall.html

          Show what you have done (screenshots)

          1 Reply Last reply Reply Quote 0
          • N
            neocleous
            last edited by neocleous

            I have yes, that is the document I initially followed, this is my configuration;

            EDIT: I just realised the pictures weren't visible, I have updated the links :)

            alt text

            alt text

            alt text

            1 Reply Last reply Reply Quote 0
