@davidstoll


Peer Network <-----WG Tunnel------> Host Network
172.16.11.0 10.6.210.0 192.168.10.0

Peer LAN Gateway | Peer Tunnel Gateway <-----WG Tunnel------> HostTunnel Gateway | Host LAN Gateway
172.16.11.1 10.6.210.2 10.6.210.1 192.168.10.1

Peer Static Route
192.168.10.0 | Gateway: 10.6.210.1

Host Static Route
172.16.11.0 | Gateway: 10.6.210.1

Yes, it is possible.

Follow this guide
https://docs.netgate.com/pfsense/en/latest/recipes/wireguard-s2s.html

Then add these configurations that I posted on this thread.
https://forum.netgate.com/topic/175495/wireguard-22-05-4100

Update:
I changed the system tunables parameters to

and the speed has increased about 2x. 250 down/up. Still not maxing out my full CPU though. Any ideas?

@itestandroid Did you ever figure this out?

I fixed it, it was my mistake.

For those of you who may come across this, here's what I did wrong:

I set the listen port for both tunnels to be the same, if I had read all of the documentation, I would have known that they need to be unique... :)

@ddbnj Feel free to fork and modify it- I had a "StateKiller" package that I was working on to do more complex rule-based state killing / failback but I sadly never finished it. Not sure how much interest there is for that now that they added some more general purpose state killing options in the recent builds.

@luckman212 it's the same as a non bgp peer.

setup bgp router options


neighbour (target system)


You need to setup frr



That's the allow all on the bgp

And setup ofcourse interface and firewall rules

This is the best I could come up with for now.

It's a pair of floating rules (block/quick) one for each direction (in/out). In the screenshot below, n_coresite_ext is an IP alias of the far end static IP/subnet, 51828 is the listen port on the far-end tunnel, and WAN2_RUT is my failover WAN interface (the one I do not want any WG traffic to traverse).

It also helps to have wgfix.sh (github) installed.


@sgc would also love to know the quick details (dont need a super detailed writeup) of how you got your WG remote access tunnel set up with SLAAC or DHCP6

@cmcdonald thank you for the explanation. indeed the problem was my frr configuration, all is working fine now.

After really long try and error I found the cause of all the mess. It is in this case mandatory to enter a MSS into the wireguard interface. I thought its calculated automatic based on MTU so 1420 - 40 = 1380. but it is not!
After entering the MSS (1380) the connection is working like charm, also with large packets and hardware offloading.

@JeGr Apropos living on the edge. 😉

Screenshot 2022-09-18 161302.png
