    my 1Gbe is detetected by pfs as 10Gbe

    Scheduled Pinned Locked Moved Hardware
    11 Posts 4 Posters 894 Views
    Loading More Posts
    • Oldest to Newest
    • Newest to Oldest
    • Most Votes
    Reply
    • Reply as topic
    Log in to reply
    This topic has been deleted. Only users with topic management privileges can see it.
    • O
      ozlecz
      last edited by

      Hello,

      Processor=c3558
      NIC=SoC
      Version=2.4.4 p3

      Installation went through but it has detetected my 4 Lan ports 1Gbe as 10Gbe. Any thoughts or solution to this?
      It is running fine but worry is there that there might be some impact on performance?

      thanks for any help in advance

      1 Reply Last reply Reply Quote 0
      • NogBadTheBadN
        NogBadTheBad
        last edited by

        What's the motherboard ?

        Andy

        1 x Netgate SG-4860 - 3 x Linksys LGS308P - 1 x Aruba InstantOn AP22

        1 Reply Last reply Reply Quote 0
        • O
          ozlecz
          last edited by

          its from sunrich and they said the NIC are MARVELL PHY 88E1543 which is SoC on 3558

          1 Reply Last reply Reply Quote 0
          • kiokomanK
            kiokoman LAYER 8
            last edited by

            can you make a screenshot of that?

            ̿' ̿'\̵͇̿̿\з=(◕_◕)=ε/̵͇̿̿/'̿'̿ ̿
            Please do not use chat/PM to ask for help
            we must focus on silencing this @guest character. we must make up lies and alter the copyrights !
            Don't forget to Upvote with the 👍 button for any post you find to be helpful.

            O 2 Replies Last reply Reply Quote 0
            • O
              ozlecz
              last edited by

              i must add you cant see the 10Gbe on the GUI..you can see it only on the console as you go to ASSIGN INTERFACES or on the list of interfaces before the menu comes up

              1 Reply Last reply Reply Quote 0
              • O
                ozlecz @kiokoman
                last edited by

                @kiokoman 1gto10g.JPG

                1 Reply Last reply Reply Quote 0
                • kiokomanK
                  kiokoman LAYER 8
                  last edited by

                  nothing to worry about, that is just the generic name that the driver think it is
                  the real speed link is what is reported on the GUI

                  ̿' ̿'\̵͇̿̿\з=(◕_◕)=ε/̵͇̿̿/'̿'̿ ̿
                  Please do not use chat/PM to ask for help
                  we must focus on silencing this @guest character. we must make up lies and alter the copyrights !
                  Don't forget to Upvote with the 👍 button for any post you find to be helpful.

                  1 Reply Last reply Reply Quote 2
                  • O
                    ozlecz @kiokoman
                    last edited by

                    @kiokoman this is better showing the ix interfaces1gto10g r1.JPG

                    1 Reply Last reply Reply Quote 0
                    • kiokomanK
                      kiokoman LAYER 8
                      last edited by kiokoman

                      yeah, i was able to zoom in on the first image, as I told you, it's only the generic name assigned by the driver.
                      the ix driver serves alot of (intel) network card, included 10gbe

                      ̿' ̿'\̵͇̿̿\з=(◕_◕)=ε/̵͇̿̿/'̿'̿ ̿
                      Please do not use chat/PM to ask for help
                      we must focus on silencing this @guest character. we must make up lies and alter the copyrights !
                      Don't forget to Upvote with the 👍 button for any post you find to be helpful.

                      1 Reply Last reply Reply Quote 1
                      • O
                        ozlecz
                        last edited by

                        so this issue was already raised prior to this thread...thanks alot..good night

                        1 Reply Last reply Reply Quote 0
                        • jimpJ
                          jimp Rebel Alliance Developer Netgate
                          last edited by

                          It's not an issue, it's normal.

                          ix is the driver. It is a 10G capable chipset and driver, but depending on the actual implementation, is perfectly happy operating at 1G or other compatible speeds/media types/etc. There are ports on the Netgate SG-5100 which are similar. They are detected as ix but the physical connection is 1G, not 10G. It will link up and run as expected at 1G.

                          Think of it similar to a 10G capable SFP port with a 1G module in it. Sure, the chip can go faster, but the media connection is only 1G.
