@krishcomment said in Free Network diagram drawing tool for Win,MAC or Linux.:
HI, @Sergei_Shablovsky
Thanks. I would like to address some concerns which you have raised here.
Regarding the shape libraries, Creately does support AWS, Cisco, GCP, Azure, and Kubernetes shapes, which can be accessed via a dedicated account.
Most of network diagramming tools that I have been testing on a real use cases may be divided on 2(two) main groups:
With ability to take attention to interface type, port speed, etc.- trying to simulate packet flow. Mostly there are hi-priced, proprietary, and with shrinked library of device’s models and in addition the ugly UI/UX interface solutions.
The shapes drawings vector editors, with full toolset (like layers, smart layers, smart groups) and rich abilities to manipulate with graphic’s objects. Polished UI/UX (especially on Apple macOS) and rich import/export features, that give ability to import any drawings from equipment/appliances manufacturer. (Most of enterprise-level manufacturers already have drawings in .ai, .svg or other vector formats).
With the trial version, these libraries aren't available, but once you have a full account, you'll be able to access them. I can also provide screenshots of these shape libraries for reference.
Please give us several screenshots.
On security, Creately is ISO 27001 and SOC2 certified, ensuring high standards of data protection. Some of our key users include the Australian government, Dubai government, NASA, and Netflix, all of whom trust Creately's enterprise-grade security. We also offer on-premise deployment options for organizations with strict security requirements.
We all see that each day some private data leaking from cloud services. Especially in Enterprise world.
I am strongly stay at point that so important, CRITICAL DOCUMENTS like network infrastructure schemes - have a MUCH BETTER SAFETY LEVEL when create, store and edit in INSIDE PERIMETER of organisation. Because a lot of abilities of internal security, both from physical to digital.
Lastly, the cloud-based nature of Creately allows for real-time collaboration and scalability, making it a powerful tool for corporate users working across distributed teams. While standalone apps have their strengths, Creately's collaborative features enhance efficiency in fast-paced environments.
Sounds like ADs. ;)
