Confirming the same results on 21.05. Would be great to have full implementation of QAT via OpenSSL so more crypto tasks could be offloaded (SSH, HAProxy, OpenVPN, etc...). Even Wireguard eventually as chachapoly is currently being integrated into dpdk for QAT offload.

[21.05-DEVELOPMENT][root@gw01]/: kldstat
Id Refs Address Size Name
1 25 0xffffffff80200000 3aebf68 kernel
2 1 0xffffffff83cec000 3bbb70 zfs.ko
3 2 0xffffffff840a8000 a448 opensolaris.ko
4 1 0xffffffff844e6000 1000 cpuctl.ko
5 1 0xffffffff844e7000 146e0 qat.ko
6 1 0xffffffff844fc000 9f521 qat_c3xxxfw.ko
7 1 0xffffffff8459c000 b28 coretemp.ko
8 1 0xffffffff8459d000 37f8 cryptodev.ko
[21.05-DEVELOPMENT][root@gw01]/: openssl engine
(devcrypto) /dev/crypto engine
(rdrand) Intel RDRAND engine
(dynamic) Dynamic engine loading support
[21.05-DEVELOPMENT][root@gw01]/: openssl speed rsa2048
Doing 2048 bits private rsa's for 10s: 3651 2048 bits private RSA's in 9.84s
Doing 2048 bits public rsa's for 10s: 125823 2048 bits public RSA's in 9.84s
OpenSSL 1.1.1k-freebsd 25 Mar 2021
built on: reproducible build, date unspecified
options:bn(64,64) rc4(16x,int) des(int) aes(partial) idea(int) blowfish(ptr)
compiler: clang
sign verify sign/s verify/s
rsa 2048 bits 0.002694s 0.000078s 371.2 12792.2
[21.05-DEVELOPMENT][root@gw01]/: openssl speed ecdhx25519
Doing 253 bits ecdh's for 10s: 77026 253-bits ECDH ops in 9.85s
OpenSSL 1.1.1k-freebsd 25 Mar 2021
built on: reproducible build, date unspecified
options:bn(64,64) rc4(16x,int) des(int) aes(partial) idea(int) blowfish(ptr)
compiler: clang
op op/s
253 bits ecdh (X25519) 0.0001s 7818.7
[21.05-DEVELOPMENT][root@gw01]/: openssl speed -evp aes-128-gcm
Doing aes-128-gcm for 3s on 16 size blocks: 32281714 aes-128-gcm's in 3.00s
Doing aes-128-gcm for 3s on 64 size blocks: 18676449 aes-128-gcm's in 2.70s
Doing aes-128-gcm for 3s on 256 size blocks: 8272172 aes-128-gcm's in 2.90s
Doing aes-128-gcm for 3s on 1024 size blocks: 2564473 aes-128-gcm's in 2.98s
Doing aes-128-gcm for 3s on 8192 size blocks: 336340 aes-128-gcm's in 2.99s
Doing aes-128-gcm for 3s on 16384 size blocks: 160840 aes-128-gcm's in 2.84s
OpenSSL 1.1.1k-freebsd 25 Mar 2021
built on: reproducible build, date unspecified
options:bn(64,64) rc4(16x,int) des(int) aes(partial) idea(int) blowfish(ptr)
compiler: clang
The 'numbers' are in 1000s of bytes per second processed.
type 16 bytes 64 bytes 256 bytes 1024 bytes 8192 bytes 16384 bytes
aes-128-gcm 172169.14k 443470.93k 730626.77k 879923.05k 920830.42k 926664.64k
[21.05-DEVELOPMENT][root@gw01]/: openssl speed -evp aes-128-gcm
Doing aes-128-gcm for 3s on 16 size blocks: 32255868 aes-128-gcm's in 2.99s
Doing aes-128-gcm for 3s on 64 size blocks: 20729035 aes-128-gcm's in 3.00s
Doing aes-128-gcm for 3s on 256 size blocks: 8243093 aes-128-gcm's in 2.88s
Doing aes-128-gcm for 3s on 1024 size blocks: 2532296 aes-128-gcm's in 2.95s
Doing aes-128-gcm for 3s on 8192 size blocks: 336769 aes-128-gcm's in 2.99s
Doing aes-128-gcm for 3s on 16384 size blocks: 168888 aes-128-gcm's in 2.98s
OpenSSL 1.1.1k-freebsd 25 Mar 2021
built on: reproducible build, date unspecified
options:bn(64,64) rc4(16x,int) des(int) aes(partial) idea(int) blowfish(ptr)
compiler: clang
The 'numbers' are in 1000s of bytes per second processed.
type 16 bytes 64 bytes 256 bytes 1024 bytes 8192 bytes 16384 bytes
aes-128-gcm 172480.46k 442219.41k 732004.53k 878076.99k 922004.94k 927182.74k
[21.05-DEVELOPMENT][root@gw01]/: clear
[21.05-DEVELOPMENT][root@gw01]/: openssl engine
(devcrypto) /dev/crypto engine
(rdrand) Intel RDRAND engine
(dynamic) Dynamic engine loading support
[21.05-DEVELOPMENT][root@gw01]/: openssl speed -engine rdrand rsa2048
engine "rdrand" set.
Doing 2048 bits private rsa's for 10s: 3630 2048 bits private RSA's in 9.79s
Doing 2048 bits public rsa's for 10s: 125602 2048 bits public RSA's in 9.83s
OpenSSL 1.1.1k-freebsd 25 Mar 2021
built on: reproducible build, date unspecified
options:bn(64,64) rc4(16x,int) des(int) aes(partial) idea(int) blowfish(ptr)
compiler: clang
sign verify sign/s verify/s
rsa 2048 bits 0.002697s 0.000078s 370.8 12779.9
[21.05-DEVELOPMENT][root@gw01]/: openssl speed -engine devcrypto rsa2048
engine "devcrypto" set.
Doing 2048 bits private rsa's for 10s: 3638 2048 bits private RSA's in 9.80s
Doing 2048 bits public rsa's for 10s: 125636 2048 bits public RSA's in 9.84s
OpenSSL 1.1.1k-freebsd 25 Mar 2021
built on: reproducible build, date unspecified
options:bn(64,64) rc4(16x,int) des(int) aes(partial) idea(int) blowfish(ptr)
compiler: clang
sign verify sign/s verify/s
rsa 2048 bits 0.002695s 0.000078s 371.0 12773.2
[21.05-DEVELOPMENT][root@gw01]/: openssl speed -engine rdrand -async_jobs 8 rsa2048
engine "rdrand" set.
Doing 2048 bits private rsa's for 10s: 3543 2048 bits private RSA's in 9.56s
Doing 2048 bits public rsa's for 10s: 124895 2048 bits public RSA's in 9.80s
OpenSSL 1.1.1k-freebsd 25 Mar 2021
built on: reproducible build, date unspecified
options:bn(64,64) rc4(16x,int) des(int) aes(partial) idea(int) blowfish(ptr)
compiler: clang
sign verify sign/s verify/s
rsa 2048 bits 0.002699s 0.000079s 370.5 12738.3
[21.05-DEVELOPMENT][root@gw01]/: openssl speed -engine devcrypto -async_jobs 8 rsa2048
engine "devcrypto" set.
Doing 2048 bits private rsa's for 10s: 3648 2048 bits private RSA's in 9.84s
Doing 2048 bits public rsa's for 10s: 125619 2048 bits public RSA's in 9.83s
OpenSSL 1.1.1k-freebsd 25 Mar 2021
built on: reproducible build, date unspecified
options:bn(64,64) rc4(16x,int) des(int) aes(partial) idea(int) blowfish(ptr)
compiler: clang
sign verify sign/s verify/s
rsa 2048 bits 0.002696s 0.000078s 370.9 12781.6
[21.05-DEVELOPMENT][root@gw01]/: openssl speed -engine rdrand ecdhx25519
engine "rdrand" set.
Doing 253 bits ecdh's for 10s: 74337 253-bits ECDH ops in 9.52s
OpenSSL 1.1.1k-freebsd 25 Mar 2021
built on: reproducible build, date unspecified
options:bn(64,64) rc4(16x,int) des(int) aes(partial) idea(int) blowfish(ptr)
compiler: clang
op op/s
253 bits ecdh (X25519) 0.0001s 7805.7
[21.05-DEVELOPMENT][root@gw01]/: openssl speed -engine devcrypto ecdhx25519
engine "devcrypto" set.
Doing 253 bits ecdh's for 10s: 75745 253-bits ECDH ops in 9.69s
OpenSSL 1.1.1k-freebsd 25 Mar 2021
built on: reproducible build, date unspecified
options:bn(64,64) rc4(16x,int) des(int) aes(partial) idea(int) blowfish(ptr)
compiler: clang
op op/s
253 bits ecdh (X25519) 0.0001s 7818.8
[21.05-DEVELOPMENT][root@gw01]/: openssl speed -engine rdrand -evp aes-128-gcm
engine "rdrand" set.
Doing aes-128-gcm for 3s on 16 size blocks: 30782618 aes-128-gcm's in 2.86s
Doing aes-128-gcm for 3s on 64 size blocks: 20747977 aes-128-gcm's in 2.99s
Doing aes-128-gcm for 3s on 256 size blocks: 8580626 aes-128-gcm's in 3.00s
Doing aes-128-gcm for 3s on 1024 size blocks: 2572191 aes-128-gcm's in 2.99s
Doing aes-128-gcm for 3s on 8192 size blocks: 320648 aes-128-gcm's in 2.85s
Doing aes-128-gcm for 3s on 16384 size blocks: 169422 aes-128-gcm's in 2.98s
OpenSSL 1.1.1k-freebsd 25 Mar 2021
built on: reproducible build, date unspecified
options:bn(64,64) rc4(16x,int) des(int) aes(partial) idea(int) blowfish(ptr)
compiler: clang
The 'numbers' are in 1000s of bytes per second processed.
type 16 bytes 64 bytes 256 bytes 1024 bytes 8192 bytes 16384 bytes
aes-128-gcm 172248.09k 443779.18k 732213.42k 880266.89k 921161.09k 930114.36k
[21.05-DEVELOPMENT][root@gw01]/: openssl speed -engine devcrypto -evp aes-128-gcm
engine "devcrypto" set.
Doing aes-128-gcm for 3s on 16 size blocks: 32215536 aes-128-gcm's in 2.99s
Doing aes-128-gcm for 3s on 64 size blocks: 19703584 aes-128-gcm's in 2.85s
Doing aes-128-gcm for 3s on 256 size blocks: 8581766 aes-128-gcm's in 2.99s
Doing aes-128-gcm for 3s on 1024 size blocks: 2575100 aes-128-gcm's in 3.00s
Doing aes-128-gcm for 3s on 8192 size blocks: 320421 aes-128-gcm's in 2.84s
Doing aes-128-gcm for 3s on 16384 size blocks: 169559 aes-128-gcm's in 3.00s
OpenSSL 1.1.1k-freebsd 25 Mar 2021
built on: reproducible build, date unspecified
options:bn(64,64) rc4(16x,int) des(int) aes(partial) idea(int) blowfish(ptr)
compiler: clang
The 'numbers' are in 1000s of bytes per second processed.
type 16 bytes 64 bytes 256 bytes 1024 bytes 8192 bytes 16384 bytes
aes-128-gcm 172264.80k 442224.00k 734222.74k 878967.47k 923037.83k 926018.22k
[21.05-DEVELOPMENT][root@gw01]/:
