@ddbnj I'm on FIOS too (NYC) and spent just about the entire week messing around with and learning the ins and outs of Verizon's implementation. There are definitely some sharp edges but I'm pretty happy now with the way things are working.

You might want to check out my helper script to assign a routable IP (GUA) to your WAN from one of the delegated prefix subnets. Link below

luckman212/assign-gua-from-iapd - GitHub

I realized the problem was my bridge so I am in the middle of a complete redesign of my network. Will post back when I know more. Hopefully the family wont object too much to the down time.

@johnpoz said in odd ipv6 routing issue:

Been in the business for some 30 years, before there was even switches.

So, you're a newcomer. I've been in the LAN business since early 1978, before there was Ethernet or IP. It was on the Air Canada reservation system, where the LAN used time division multiplexing over coax @ 2 Mb or triaxial cable @ 8 Mb. I started in telecom in May 1972.

@roycethebiker

Did you select 56 for the prefix size?

Looks like a bug has been filed by the dev team.

It is set on for me per my above post. But, I am on 2.6.0 (which is 22.2 config rev).

@pfadmin

Assuming you want access from elsewhere, how would that help? You still have to allow the outside world to know what the address is.

@jagdtigger

You said an ordinary computer doesn't work. Try complaining about and see what they say. I know it can sometimes be difficult to get through support.

@ddbnj said in Site to Site ipv6 best practice GUA vs ULA:

I'm still using IPv4 tunnels but am transmitting IPv6 packets across.

I do the same. I don't run the tunnel over IPv6 due to DNS issues. My IPv4 address is an alias that points to the ISP provided host name. Using the alias prevents the DNS server from returning the IPv6 address, which is a regular AAAA record. However, pfSense is configured to allow either IPv4 or IPv6.

@jarhead said in xfinity/comcast ipv6 issue:

But the CGNAT issue I agree with and is valid. Other than that, no reason for IPv6.

When NAT first came out, it broke FTP clients.
It breaks VoIP and some games, requiring STUN to get around it.
It breaks IPSec authentication headers.
It adds work load to routers.
IPv6 provides far more than enough addresses.
IPv6 adds security features.
IPv6 improves router performance.
Etc..

@jknott

The packet capture via mac address is a good idea. If I decide to create an IPv6 table for my local devices, I'll use it.

Regarding routing, I realized that I have to add a route for ULA devices if I don't create an address for the interface itself. It's for devices on a different VLAN to reach ULA devices (admin to IOT).

Anyway, thanks for your insights. Learning and deploying IPv6 has been pretty time consuming, I got to catch up with my real life!

Thanks,

Devan

@mloiterman Make a /128 Virtual IP address on your WAN in on of the /64s you want to route downstream. Make a WAN rule passing ICMP6 to that address. Ping it from the outside. Until that works you're not going to be able to route it downstream.

pfSense is doing what it's supposed to be doing with the /64s on a tracked inside interface. That doesn't mean it's a new delegation. Just that dhcpd is adding that prefix to that interface from the delegation.

Go to System > Advanced, Networking and enable the debug on dhcp6c. Then edit/save WAN. Then go to Status > System Logs, DHCP and filter on Process: dhcp6c. See what is there. That should show you the prefix that was assigned.


I only keep zipping files since this webpage doesn't accept my native uploads. The screenshots have to be less than 2MB or they get rejected. The only way I could get the screenshot that small was to make it a PDF file which isn't accepted. Saving it as a .BMP or .JPG the file was just over 2MB and wasn't accepted.

Frank

So, I found a GUI "bug". I had correctly set the prefix ID's in the "Tracked Interface" for each VLAN, but at the RA page, I mistakenly reinserted the prefix ID in the fields that are for static (full, not delegated) prefixes. Removed the static prefixes and everything now works. GUI should not let you enter static prefixes on a tracked interface, aside from fc00 or fd. And if it does, it should check if they are correct. One of the prefixes was ::1/64.

@noviceiii

Here's an example of what I'm looking for in the captures. This is just part of one packet of 8.


@cyth I did a clean installation of pFSense out of the box provided IPV6, without changing any settings. Looks like they just started rolling dual stack so it will be some issues until they figure it out and finish the implementation. So far my pFSense is working, no issues with internet IPV6 traffic. From Verizon Automatic provide to pFSense address size.

Then I upgraded to pFSense plus, no issues working our of the box.

I spend a lot of time tried to figure it out, and looks like all this time was Verizon implementation issues.

I found out I started getting IPV6 because, some of my devices stop working, the reason was because those devices tried to communicate only using IPV6, they were giving priority over IPv4.

@zennb1

Clients rely on router advertisements to learn the LAN prefix and they append the suffix to it. Run Packet Capture, filtering on icmpv6, to see if you have them. You could also run Wireshark on a computer to do the same thing.
