@justme2
Get your SFTP browser, open /usr/local/www/services_dhcp_relay.php
Or use the console or SSH, and edit /usr/local/www/services_dhcp_relay.php
Locate :
if ($dhcpd_enabled) {
print_info_box(gettext('DHCP Relay cannot be enabled while DHCP Server is enabled on any interface.'), 'danger', false);
}
Chance for :
if ($dhcpd_enabled) {
print_info_box(gettext('DHCP Relay cannot be enabled while DHCP Server is enabled on any interface. !! OVERRIDDEN !!'), 'danger', false);
$dhcpd_enabled = false;
}
Note : the "!! OVERRIDEN !!" is my personal choice, and not needed.
Save.
Now, for example : I disabled the DHCP server (kea) for this interface :
[image: 1757669144546-1208eea8-273b-4632-aa28-447a19ca7d92-image.png]
Save and Apply.
Back to DHCP relay, select IDRAC - add a DHCP Relay server :
[image: 1757669183530-4a1df8ab-bc3b-41ce-9da3-edd2d04bfacc-image.png]
and Save.
Check :
[25.07.1-RELEASE][root@pfSense.bhf.tld]/root: ps aux | grep 'dhc'
root 26880 10.2 0.6 43768 23968 - S 11:18 0:00.10 /usr/local/sbin/kea-dhcp4 -c /usr/local/etc/kea/kea-dhcp4.conf
root 27281 9.9 0.6 43728 23532 - S 11:18 0:00.09 /usr/local/sbin/kea-dhcp6 -c /usr/local/etc/kea/kea-dhcp6.conf
root 24435 0.0 0.1 14404 2980 - Is 20Aug25 0:00.02 dhclient: system.syslog (dhclient)
root 41257 0.0 0.1 14404 3100 - Is 20Aug25 0:00.05 dhclient: ix3 [priv] (dhclient)
root 51257 0.0 0.1 14308 3460 - SCs 20Aug25 0:39.41 /usr/sbin/syslogd -O rfc5424 -s -c -c -l /var/dhcpd/var/run/log -P /var/run/syslog.pid -f /etc/syslog.conf -b 192.168.1.1
_dhcp 51487 0.0 0.1 14408 3268 - SCs 20Aug25 0:05.22 dhclient: ix3 (dhclient)
root 52757 0.0 0.1 14128 2900 - Is 20Aug25 0:06.00 /usr/local/sbin/dhcp6c -d -c /var/etc/dhcp6c.conf -p /var/run/dhcp6c.pid ix3
root 56422 0.0 0.1 16812 4776 - Is 11:10 0:00.00 /usr/local/sbin/dhcrelay -id igc2 -iu ix3 192.168.10.1
The kea DHCPv4 is still running. If all goes well, it doesn't touch/use the igc2 - my "IDRAC" - interface.
As you can see, dhcrelay is running also - using 'igc2' - my IDRAC interface.
You'll notice that on the DHCPv4 (kea, as that's what I'm using) there are also red messages showing.
[image: 1757668428078-c8d71175-a0b8-4fd6-b081-18138c5027b5-image.png]
Also for the LAN, and other interfaces.
I guess you know now how to make these GUI pages more "smart", and don't show messages if they are not needed.
On the DHCP Relay GUI page you could even modify the list with shown network, by excluding the networks that have the DHCPv4 active on them.
In my case : this list should only shown "IDRAC" instead of :
[image: 1757669589057-fe81bc41-f103-4a54-be83-890688b52a39-image.png]
Btw : I did not test this dhcrelay service. I don't have a network where this is needed / don't know how to use it.
Also : I presume you cant' save DHCOPv4 ((kea) settings and network pages anymore, as on this pages the test 'is dhcp relay' running also exist (Generaol settings page : just the test, on the interface(s) page - the same PHP file is used for all interfaces the test also exist, and name some love).
I'll leave it up to you a make something nice, safe and fool proof out of it.
Like : If you select an interface, like my IDRAC, that has a dhcp relay activated on it, show the red message and don't allow the user to Enable it with an active DHCP server. This is now already the case. Make the code a bit smarter by testing the (this) interface is used by dhcp relay, and only allow the DHCP server (kea) to be activated on that interface if it is not used by dhcp relay.
See /usr/local/www/services_dhcp.php- here :
[image: 1757669965048-4812bf5d-0bca-4afb-a4f0-8e0173cd984f-image.png]
how to make these decisions.
